SANDWICH ELEMENTS

FOR WALLS AND ROOFS

Their excellent structural properties make sandwich plates ideal building materials for walls and roofs. They consist of two steel cover sheets with an inner rigid foam core.

Sandwich panels, also called insulation panels, are suitable as
…
…wall cladding
…roof cladding
…a partition

…a false ceiling.

They stand out as a space enclosure, weather protection, as well as thermal insulation.

All sandwich panels are very lightweight and very rigid. This translates into large spans. All panels combine economy, easy assembly and practicality.
Any processing is quick and simple.

COVERS

LONG-TERM AND AESTHETICALLY PLEASING

We carry a wide range of wall and roof elements in many varieties, styles and thicknesses from 30mm to over 200mm.

Please give a call for binding information on our current prices and on possible assortments and colors.

WALL PANELS

RANWAND Standard
Wall with normal mounting
RANRIGHE
Wall with normal mounting
RANWAND GSB
Wall with smooth surface
and standard mounting
RANWAND VB
Wall with hidden mounting
RANWAND GVB
Wall with smooth surface
and concealed mounting
RANWAND MICRO
Wall with micro-lined surface
and concealed mounting
RANWAND K
Wall for cold-storage rooms
with normal mounting
RANWAND W
Wall with rippled surface
and concealed mounting
RANWAND SE MICRO
Flame retardant wall
with micro-lined surface
and concealed mounting
RANWAND SE Standard
Flame retardant wall
with normal mounting
RANWAND SES
Flame retardant
and sound absorbing wall
with normal mounting

ROOF PANELS

RANDACH Standard 5
RANDACH Grecata
RANDACH Brick-look
RANDACH Welle
RANDACH 3
RANDACH 40
RANDACH SE
Flame retardant roof
RANDACH SES
Flame retardant
and sound absorbing roof

ACCESSORIES

FOR YOUR PROFESSIONAL INSTALLATION

Caps To cover screw heads with a colored PVC cap.
Sealing tape Expanding sealing strip for insertion into the joints of panels.
Optimal for sealing purposes and as a vapor barrier.
Transluscent rooflights Permit the mounting of fixed light elements in roofing structures with single-or double-skin panels.
Calottes For cladding, covering and bracing purposes.
End profile For closing profile beading purposes.
Temperature resistance -40 ° C to +70 ° C
Serrated ridge caps For connecting both roof surfaces with a two-part, hinge-like assembled element that has the same beading profile as the panels.
Screws for pre-drilling A pilot hole is required for mounting thermal insulation panels and trapezoidal and corrugated sheets to metal substructures. For structures more than 2.5 mm thick.
Self-drilling steel screw A pilot hole is required for mounting thermal insulation panels and trapezoidal and corrugated sheets to metal substructures, a pilot hole is required. For structures more than 2.5 mm thick.
Drilling screw No pilot hole is required for external thermal insulation panels and trapezoidal and corrugated sheets to metal substructures - a significant reduction in assembly time and deployed labor is guaranteed.
Self-drilling wood screw For mounting thermal insulation panels and trapezoidal and corrugated iron sheets on wooden substructures.
Screws for RANDACH brick-look and RAN-50/600-750 A pilot hole is required for mounting RANDACH brick-look and RAN-50/600-750 panels on metal substructures. Suitable for structures up to 6 mm thick. Also available for mounting on wooden substructures.
Profile filler Sealing tapes for installing panels.
Curved rooflights Permit the mounting of fixed light elements in curved roofs.
